240GB M.2 2280 SSD, NVME, Industrial, T445 Cervoz, Wide-Temp
SKU
CIE-M8T455MMH240GW
Lead time 14-22 days
Industrial M.2 2280 Embedded Module (High-Endurance)
- Compliant with PCIe Gen 4x4 interface
- Compliance: NVMe 2.0 / PCI Express Base 4.0
- 3D TLC flash memory
- Capacity: 240GB ~ 1920GB
- Over-provisioning technology
- Dynamic SLC Cache technology
- Safeguard / Circuitguard
- Single-Sided Design
- Write Protect Function (Optional)
- Dynamic Thermal throttling
- MIL-STD-810H Compliant (Optional)
| Form Factor | |
| Form Factor | M.2 PCIe 2280 |
| Product grouping | Industrial M.2 2280 Embedded Module |
| System | |
| Interface | PCIe Gen4x4 |
| Connector & Form factor | M.2 2280 (M-key) |
| NAND Flash type | 3D TLC |
| Capacity | 240GB – 1920GB |
| Sequential Read | up to 5080MB/s |
| Sequential Write | up to 4740 MB/s |
| DRAM buffer | no |
| ECC Scheme | LDPC |
| MTBF | >3 000 000 h |
| Supply Voltage | 3.3V DC |
| Dimensions | 80mm x 22mm x2.2mm |
| Specialty Technology | Over-provisioning technology Dynamic SLC Cache technology Safeguard / Circuitguard End-to-End data protection Dynamic Thermal throttling Anti-Vibration Fill (Optional) Conformal Coating (Optional) |
| Environmental | |
| Operating Temp | Standard : 0°C ~ 70°C Wide : -40°C ~ 85°C |
| Manufacturer / Brand | Cervoz |
|---|---|
| Capacity | 240GB |
| Interface (Connector) | M.2 M-key |
| Data Interface | NVMe /PCIe Gen4x4 |
| Operating Temp | Normal Temp 0..70C |
