960GB M.2 2280 SSD, NVME, Industrial, T441 Cervoz

SKU
CIE-M8T441ONV960GS
Lead time 14-22 days

Industrial M.2 2280 Embedded Module

  • Compliant with PCIe Gen 4x4 interface
  • Compliance: NVMe 1.4/ PCI Express Base 4.0
  • TLC NAND flash memory
  • Capacity: 480GB ~ 3840GB
  • With DRAM Buffer
  • End-to-End data protection
  • SLC write cache technology
  • Dynamic Thermal throttling
  • Operating as boot disk
  • Static and dynamic wear leveling
Form Factor
Form Factor M.2 PCIe 2280
Product grouping Industrial M.2 2280 Embedded Module
System
Interface PCIe Gen4x4
Connector & Form factor M.2 2280 (M-key)
NAND Flash type 3D TLC
Capacity 480GB – 3840GB
Sequential Read up to 7100MB/s
Sequential Write up to 6190 MB/s
DRAM buffer yes
ECC Scheme LDPC
MTBF >3 000 000 h
Supply Voltage 3.3V DC
Dimensions 80mm x 22mm x3.5mm
Specialty Technology End-to-End data protection
SLC write cache technology
Dynamic Thermal throttling

Anti-Vibration Fill (Optional)
Conformal Coating (Optional)
Environmental
Operating Temp Standard : 0°C ~ 70°C
Wide : TBC
More Information
Manufacturer / BrandCervoz
Capacity960GB
Interface (Connector)M.2 M-key
Data InterfaceNVMe /PCIe Gen4x4
Operating TempNormal Temp 0..70C
