InnoEx ETC22
SKU
EA1-9NETC2201401
Lead time 21-30 days
LAN to Dual CAN Bus 2.0B
- Expands I/O through virtualization technology
- Simulate remote I/O on local computer
- Keeps I/O behavior and data format. No change of I/O operation
- Meets the requirements of the ISO 11898-1
- Supports PoE connection compliant with IEEE 802.3at/af
- Supports CAN message acceptance filter
| Processor | |
| Interface | LAN to Dual CAN Bus 2.0B |
| Controller | - |
| Function | InnoEx Virtual I/O |
| Input I/F | LAN |
| Output Port | 2 |
| Output Connector | DB9 |
| CAN Communication | CAN2.0b |
| Vibration /Shock | 5G @ [7~2000Hz] 50G@0.5ms |
| Temperature | Operation : W/T -10°C ~ 85°C (Ta) Storage : -20°C ~ 90°C (Ta) |
| OS Supoort | Windows : 10 (32 / 64bit), and above version Linux : SocketCAN driver from Kernel 2.6.38 and above (32 / 64bit) |
| Dimension | 105x 118 x 23mm |
| Notes | |
| Manufacturer / Brand | Innodisk |
|---|
