MPC241
SKU
MPC241
Lead time 21-30 days
24" medical panel PC with Intel® Core™ Ultra 5/7 processor, 4 USB 3.2 Type-A, 1 USB 3.2 Type-C, 1 HDMI 2.1, two 2.5GbE LAN, dual 2W speakers, and optional RFID module or MXM GPU module
- 24" full HD display with multi-touch P-CAP control screen
- AI acceleration with Intel® Core™ Ultra 5 or Ultra 7 processor
- 2 DDR5-5600 SO-DIMM, up to 96GB memory
- Advanced computing ability integrated with MXM GPU module
- IP65 front bezel and IPX1 full enclosure design
- Optional cable trays for effortless cable routing
- RFID reader and COM port integration (optional)
| System | |
| Processor | Intel® Core™ Ultra 7/5 Processor (Series 1), up to 45W |
| CPU Performance | |
| Security Hardware |
TPM 2.0 |
| Chipset | SoC |
| Storage | 2 x M.2 Key M 2280 support NVMe SSD |
| Memory | 2 x DDR5-5600 SO-DIMM, up to 96 GB |
| Display | |
| Screen Size | 24" TFT LCD |
| Screen Resolution | 1980x1080 |
| Display Ratio | 16 ::9 |
| Contrast Ratio | |
| Brightness | 350 nits |
| Viewing Angle | 178(H); 178(V) |
| Number of Colors | |
| Touch Screen | |
| Touchscreen | Projected capacitive 10-point multi-touch |
| I/O Ports | |
| USB 2.0 | |
| USB 3.0 | 4x USB 3.2 1 x USB Type-C, supports PCIe Gen 3 x4 lanes/USB 3.2/PD 15W/DP Alt mode |
| Serial | 1 x COM (RS-232) with 1.5kV isolation (optional) |
| Video | 1 x HDMI 2.1 |
| Ethernet | 2 x 10/100/1000/2500 Mbps Ethernet (1.5kV isolation, Intel® I226-LM) |
| Other Ports | 2 x audio (2W speakers, HD codec audio with Mic-in/Line-out using Realtek ALC888s) |
| Operating System | |
| Operating System | Windows 10 IoT, Windows 11 IoT |
| Power | |
| DC Input / Source Voltage | 24V DC input with medical-grade 250W PSU |
| Power Management | |
| Expansion Slots | |
|
1 x PCIe Gen 4 x4 (x16 slot) for MXM GPU module |
|
| Multimedia | |
| Integrated Speakers | - |
| Operating Temperature | |
| Operating Temperature | 0ºC to 40ºC |
| Humidity Range | 10% to 95% non-condensing |
| Cooling System / Thermal Solution | |
| Thermal Solution | |
| Dimensions / Weight | |
| Weight (kg) | 8 kg |
| Dimensions | 548 x 62 x 350 mm |
| Enclosure | |
| Bezel | |
| Material | |
| Mounting |
|
| Note * | |
| Peripherals & Devices | |
| Accessories | |
| Extra Features | |
| Certification | |
| Certification |
CE, FCC Part 18 |
| Manufacturer / Brand | Axiomtek |
|---|---|
| Display Size | 24" |
| Touch type | Projected Capasitive (PCAP) |
