SSD3325-Y

SKU
SSD3325-Y
Lead time 21-30 days

33.2" TFT LCD, LED Backlight 1000 nits, FHD 1920x1920

  • 33.2" square-shaped LCD high brightness (1,000 nits)
  • Square display (aspect ratio of 1 : 1)
  • Slim bezel
  • Low power consumption
  • Long lasting 24/7 operations
  • MTBF: 70,000 hours
Display
Screen Size 33.2" TFT LCD
Screen Resolution 1920x1920
Display Ratio 1 ::1
Contrast Ratio 600 ::1
Brightness 1000 nits
Viewing Angle 178°(H),178°(V)
Number of Colors 16.7M
Touch Screen
Touchscreen -
I/O Ports
Video

1x DisplayPort
1x DVI-D
1xHDMI

Other Ports
Operating System
Operating System
Power
DC Input / Source Voltage 12V DC input

Multimedia

Operating Temperature
Operating Temperature 0ºC to 50ºC
Humidity Range 10% to 95% non-condensing
Cooling System / Thermal Solution
Thermal Solution
Dimensions / Weight
Weight (kg) 11.5 kg
Dimensions 615.8x615.8x62.9mm
Enclosure
Bezel size
6.9/6.9/6.9/6.9mm
Material
Mounting VESA 400x200, 400x300
Protection
Peripherals & Devices
Accessories
Extra Features
Certification
Certification CE / FCC
