SCD2365-Y
Tuotenro
SCD2365-Y
Toimitusaika 21-30pv
23.6” TFT LCD, LED Backlight 1000nits, 1920x1920, Circle Display
- 23.6" Circle Display
- High Brightness 1000nits
- Sunlight Readable
- Aspect ratio 1:1
- Programmable Pattern RGB Circle Lighting
- RGB LightingBL
- MTBF: 100,000 hours
| Display | |
| Screen Size | 23.6" TFT LCD |
| Screen Resolution | 1920x1920 |
| Display Ratio | 1 ::1 |
| Contrast Ratio | 600 ::1 |
| Brightness | 1000 nits |
| Viewing Angle | 178°(H),178°(V) |
| Number of Colors | 16.7M |
| Touch Screen | |
| Touchscreen | PCAP |
| I/O Ports | |
| Video |
1x DVI-D |
| Other Ports | USB Touch |
| Operating System | |
| Operating System | |
| Power | |
| DC Input / Source Voltage | 230V AC |
| Multimedia | |
| Operating Temperature | |
| Operating Temperature | 0ºC to 50ºC |
| Humidity Range | 10% to 95% non-condensing |
| Cooling System / Thermal Solution | |
| Thermal Solution | Passive - Fanless |
| Dimensions / Weight | |
| Weight (kg) | 24 kg |
| Dimensions | 890 x 890 x 77mm |
| Enclosure | |
| Bezel size |
|
| Material | |
| Mounting | VESA 200x400 , 400x400 |
| Protection | IP65 Front |
| Peripherals & Devices | |
| Accessories | |
| Extra Features | |
| Certification | |
| Certification | CE / FCC |
| Näytön koko | 24" |
|---|---|
| Näytön signaali (input) | DVI-D, HDMI, Display Port |
