ESPC-F4S3-W1 PCIe to Four Isolated CAN FD Module

Tuotenro

ESPC-F4S3-W1

Toimitusaika 21-30pv

PCIe to Four Isolated CAN FD Module

Baud rate up to 5 / 10 / 20 / 50 / 100 / 125 / 250 / 500 (default) / 800 / 1000K
CAN2.0 up to 7,800 frame/s (RX baud rate 1M, EID, 8byte data)
CANFD up to 6,000 frame/s (RX baud rate 1M, data rate 5M, EID, 64byte data)
Data rate supports 2 / 4 / 5Mbps
Complies with IEC 60950-1 : 2005 + A1 : 2009 + A2 : 2013 2.5kV HiPOT protection
Complaint with EN61000-4-2 (ESD) Air-15kV, Contact-8kV
Termination resistor enabled / disabled by jumper
Optional M.2 slot to expand 2 ~ 4 more CAN ports by installing EGUC series

Processor
Interface	PCIe
Controller	-
Function	CAN FD
Input I/F	PCIe v2.0 x1
Output Port	4
Output Connector	DB9
CAN Communication	CAN FD
Vibration /Shock	5G @ [7~2000Hz] 50G@0.5ms
Temperature	Operation : W/T -40°C ~ 85°C (Ta) Storage : -55°C ~ 95°C (Ta)
OS Supoort	Windows : 10 (32 / 64bit) and above version Linux : Kernel 2.6 and above (Native CDC-ACM driver), Kernel 2.6.38 and above (SocketCAN Driver), 32 / 64bit
PCB Dimension	111.15 x 110 x 16.79 mm
Notes	*Data rate limitation : ● 2M supports normal rate 100k and above. ● 4M / 5M supports normal rate 250K and above.
