Industrial I/O Control PCIe Card 8+8-ch Isolated Digital I/O

  • Expands isolated eight (8) digital input channels with features for all channels.
    • Support both NPN & PNP devices
    • Support both dry and wet contact connections
    • With digital filter for noise reduction
    • Built-in 32-bit counter for all digital in channels
  • Expands isolated eight (8) NPN type digital output channels with initial value (Booting & Restart) protection.
  • Each channel built-in 2.5KV isolation protection for signal and power, allowing the input signals to be completely floated so as to prevent ground loops
  • Designed to meet PCI Express Base Specification Revision 2.1.
  • With high reliable SUNIX QiuNiu UART Digital-I/O controller.
  • Plug-n-Play, I/O address and IRQ assigned by system.
Interface PCI Express
Controller SUNIX QiuNiu UART Digital-I/O Controller
BUS PCI Express 1.0 x1
IRQ & IO Assigned by System
ESD Protection ±15KV IEC61000-4-2 Air Gap Discharge
±8KV IEC61000-4-2 Contact Discharge

Digital Input Communication
Type NPN & PNP
Channel 8-Channel
Dry Contact Logic Level 0: Open;
Logic Level 1: Close to GND
Wet Contact Logic Level 0: 0 to 3VDC;
Logic Level 1: 10 to 50VDC
Pin Define DI1~DI8, COM, GND
Counter 32-bit counter for all channel
Interrupt Mode Event trigger (Rising Edge, Falling Edge, Both modes) & polling for all channels
Noise Reduction Digital Filter

Digital Output Communication
Type NPN
Channel 8-Channel
Voltage Range 3.5 to 40VDC
Current 500mA per Channel
Pin Define DO1~DO8, PWR, GND
Initial Protection Initial Value Setup (Booting & Restart protection)
I/O Multi I/O
Valmistaja Sunix
Connection PCIEx1
