Niceview 15.6" FULL-HD Sun Readable TFT Teollisuus Kosketusnäyttö
Tuotenro
tft156hb-v2
Toimitusaika 8-16pv
715,35 EUR 570,00 EUR
15.6" FULL-HD Sun-Readable TFT Touch monitor (PCAP)
- 1000nits Hi-Brightness
- Auto-Dimming
- IP65 front panel
- 16:9 Wide-screen (1920*1080)
- PCAP 10-point multitouch (USB)
- Metal frame, Aluminium front panel
- VESA75/100, Panel mounting
- HDMI, VGA, RCA, audio input
Pakkaus sisältää
- Monitori
- Verkkovirtalähde
- Paneeliasennus kiinnikkeet
- HDMI-kaapeli
- VGA-kaapeli
- USB-kaapeli kosketuspinnalle
- RCA-kaapeli komposiittivideolle
- 3.5mm - RCA Audio sisään kaapeli
HUOM! Jalusta ostettava erikseen!
| Display | |
| Screen size | 15.6 inch |
| Resolution | 1920*1080 |
| Proportion | 16:9 |
| Gray-scale response time | |
| Panel Type Industrial | Control A style TFT |
| Point distance | 0.264mm |
| Contrast | 1000:1 |
| Backlight type | LED, use length≥50000h |
| Display color | 16.7M |
| Visual angle | 160/160° |
| Brightness | 1000 nits |
| Touch Screen | |
| Touch-type | 10-points capacitive |
| Number of touches | ≥ 50 million times |
| I/O ports | |
| Signal Interface | HDMI, VGA, RCA |
| Power connector | DC with ring attachment |
| Touch interface | USB |
| Other interfaces | Audio 3.5mm ear jack |
| Audio | 2 speakers |
| Power | |
| Power Supply | 4A External Power Adapter |
| Power Performance | 100-240V, 50-60HZ |
| Input voltage | 12-24V |
| Anti-static | Contact 4KV-air 8KV |
| Power | ≤25W |
| Dimensions / Weight | |
| Dimensions | 408 x 259 x 37mm |
| Enclosure | |
| Anti-vibration | |
| Anti-interference | EMC|EMI anti-electromagnetic interference |
| Dustproof and waterproof | Front IP65 dustproof and waterproof |
| Housing Material | Black, metal alloy |
| Installation method | Embedded, desktop, wall-mounted, VESA 75, VESA 100, panel mount, open frame. |
| Operating temp | |
| Ambient temperature | <80%, non-condensable |
| Working temperature | 0°C～50° |
| Weight | 2.9kg |
| Valmistaja / Brand | Niceview |
|---|---|
| Näytön koko | 15.6" |
| Kosketusominaisuuden tyyppi | Projected Capasitive (PCAP) |
| Näytön signaali (input) | VGA, HDMI, Composite Video (RCA) |
