FPC-7502

Tuotenro
fpc-7502
Toimitusaika 14-22pv
Rugged Fanless PC with Intel Socket G Core i5/i7
Ominaisuudet
* Fanless Design
* Wide Range DC Power Input (10 ~ 28V)
* Serial port with 5V/12V power output
* Rugged Design for Shock/Vibration Protection
* Rich Onboard I/O and Expansion Slots (1 x PCIe x1, 1 x PCIe x16, 1 x Mini-card, 1 x SIM socket)
* Support Various Video Interfaces (Analog RGB, DisplayPort)
* Support Outside Accessible CFAST Slot
* Support DDR3 SO-DIMM up to 8GB
Pakkaus sisältää
FPC-7502
*Intel Core i5 Mobile Processor i5-520M 2.4GHz CPU
Spesifikaatiot
Processor Core Logic System

CPU:
Intel Socket G Core i5/i7 series processors

Chipset:
Intel QM57

System memory:
2 x 204-pin Dual Channels DDR3 SO-DIMM Sockets up
to 8GB at 800/1066MHz

Graphics
Integrated Intel HD Graphics controller


Ethernet
Interface: 2x 10/100/1000 Mbps Gigabit Ethernet
Controller: 2 x Intel® WG82574IT Gigabit Ethernet controllers

I/O expansion
1 x DB-44 female connector (Support 4 x RS-232 ports
COM3,4 is RS-232/485 selectable)
1 x PS/2 Keyboard & Mouse
1 x VGA port
1 x DVI
1 x Displayport
8 x USB 2.0
2 x RJ45 Port
Mic-in/Line-out (6W pre-amplified)


Power Supply
DC 10~28V input (w/ 4-pin DC input terminal block
combine remote power on/off switch)

Expansion Slot
1x PCIe x16 slot
1 x PCIe x1 slot
1 x Mini-card slot

HSUPA 3.75G(optional Mini-card)
1x SIM Card slot

Storage
1 x 2.5" drive bay for HDD/SSD
1 x CFAST Socket which can be outside accessible

Mechanical
Construction:Aluminum alloy
Mounting: Wall-mount(Default integrated)/Din rail mounting
Dimensions: 195 x 268 x 110 mm


Environment Specifications
Operating Temp: -20 ~ 55°C , ambient w/ air flow
(with industrial hdd)
Storage Temp: -40 ~ 85°C
Relative Humidity: 10 ~ 95% @ 40°C (non-condensing)
