FPC-8107

Tuotenro
FPC-8107-1E2P
Toimitusaika 21-30pv

Robust Box PC with Intel® 10th Generation Core™ i9/i7/i5/i3 Processor

  • Fanless design
  • Wide range DC power input (9~36V)
  • Two independent displays support (HDMI x 1 + VGA x 1 and DVI-D x 1)
  • Power on/ off delay control/ configurable ignition power control
  • TPM2.0 support
  • 1 x mPCIe for optional Wi-Fi/ 3G/ 4G/ GPS or I/O expansion supported
  • Up to 3x expansion slot support
    *1x PCIEx16 , 2x PCI
  • 1 x M.2 E Key (2230) for Wi-Fi/ Bluetooth
  • Front-accessible I/O support
  • Intel Wi-Fi 6 AX200 support
Muokkaa FPC-8107
FPC-8107

* Pakolliset kentät

Tuote
FPC-8107
FPC-8107

0,00 EUR

Yhteenveto
    System
    Processor 10th generation Intel® Xeon® Core™ i9/i7/i5/i3 processor in LGA1200 socket
    CPU Performance
    Security Hardware
    Chipset Intel® W480E Chipset
    Storage 2 x Serial ATA ports with 600MB/s HDD transfer rate
    2 x 2.5” drive bays (outside accessible)
    Storage Support
    Memory 2 x 260-pin DDR4 SO-DIMM sockets, supporting 2933 ( i9/ i7 CPU)/2666( i5/ i3 CPU)/2400 MHz (Pentium/ Celeron CPU) SDRAM up to 64GB (ECC / Non-ECC)
    Graphics Integrated Intel® HD Graphics
    I/O Ports
    USB 2.0 1 x USB2.0 (internal)
    USB 3.2 2 x USB 3.2 (10Gbps)
    4 x USB 3.2 Gen1 (5Gbps)
    Serial 2 x RS-232/422/485
    Video 1 x HDMI
    1 x VGA
    Ethernet 1 x RJ-45 ports for 2.5GigE
    3 x RJ-45 ports for GbE
    Other Ports Mic-in/Line-out
    16 x DI
    16 x DO
    Expansion
    Expansion Interface 1 x mPCIE with SIM for optional Wi-Fi / BT / 3G / LTE / GPS (PCIe x 1+USB 2.0, Full Size)
    1 x M.2 E key (2230) with PCIe x 1+USB2.0, for Wireless
    1 x M.2 B key (2242 / 3052 / 2280) w/ (PCIe x 2 + USB 3.0 + SATA) with SIM for 5G / LTE expansion or for storage (either one)

    2 x PCIe x16 slot (via x 8 lanes) or 1 x PCIe x16 slot (via x 16 lanes)
    1 x PCIe x4 slot (power budget 25W)
    Operating System
    Operating System Windows® 10, Linux
    Power
    DC Input / Source Voltage Main Power Input:
    12~36VDC

    Secondary Power Input:
    12~36VDC for GPU card power

    Ignition Switch
    Operating Temperature
    Operating Temperature -20°C ~ +70°C with W.T. SSD, 35W TDP CPU
    -20°C ~ +55°C with W.T. SSD, 65W TDP CPU
    -20°C ~ +50°C with W.T. SSD, 80W TDP CPU
    Humidity Range 10% ~ 95%, non-condensing
    Cooling System / Thermal Solution
    Thermal Solution Passive - Fanless
    Dimensions / Weight
    Weight (kg) 7.5 kg
    Dimensions 181 x 320 x 250 mm
    Enclosure
    Material Aluminum / Steel
    Mounting Desk / Wall mounting
    Certification
    Certification CE, FCC
    Lisätietoja
    Jäähdytys Fanless
